Container semi-trailer used and brand new
- Low price/solid quality / high cost performance
Container semi-trailer
Excellent quality and high reliability
Vehicle exterior and interior completely renovated
Fastest possible delivery; on-time delivery based on customer demand
High cost performance
Technical features
The cargo part is a semi-trailer with a container structure. Mainly used in logistics systems such as ships, ports, routes, highways, transfer stations, bridges, tunnels, and multimodal transport. Specially used for the transportation of various containers to facilitate the filling and emptying of goods to meet the individual needs of customers.
The box shell is made of high-strength corrugated steel plate (anti-wave) or flat steel plate. The internal part adopts a frameless structure to maximize the load-bearing capacity. X-shaped tension braces secure the cabinet into a very strong unit.
The side guards adopt a closed design, which effectively reduces lateral risks, reduces energy consumption, and allows fast operation. Reasonable trailer accessories are placed in the rear protective box for easy use.
PERFORMANCE PARAMETER
Total Weight | 39300 kg |
Rated Load | 31000, (30800) kg |
Tare Weight | 8500,8300 kg |
Wheel Base | 7100+1310+1310 (mm) |
Tyre Specifications | 11.00R20 12PR 12R22.5 12PR(Vacuum tyre or rail tyre) |
No. Of the Tyres | 12 |
Axle Brand | FUWA (BPW optional) |
No. Of the Axles | 3 |
Axle-load | 24000 kg |
Pieces of leaf-spring | 10 (8) (4) |
Suspension | is constitute by tandem steel plate spring and bearing legs. |
Departure Angle | 14.2 |
Front/Rear Overhang | 2160 mm |
Outside Dimensions (LxWxH) | 13000X2550X3850 3650,3450 (mm) |
Interior Dimensions (LxWxH) | 12800X2350X2200 2000,1800 (mm) |
Material of the Main Beam | Q235A manganese plates, automatic submerged arc welded |
Brake System | ABS (optional ) |
